Digital Meter Dashboard DZ97189584116 SHACMAN
| Product Name | Digital Meter Dashboard |
| Product Number | DZ97189584116 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | Carton |
| Application | SHACMAN |
| Original | China |
Product Description
Product Introduction
This Digital Meter Dashboard DZ97189584116 is an OEM intelligent instrument assembly exclusively developed for Shacman heavy-duty truck models. It adopts a integrated ergonomic design, combining analog mechanical gauges (tachometer 0–2500 rpm, speedometer 0–140 km/h) with a high-resolution central digital display screen, all enclosed in a scratch-resistant PC cover and a robust ABS plastic housing. The assembly features a full-sealed circuit board with anti-electromagnetic interference (EMI) treatment and a reinforced shock-absorbing mounting structure, engineered to withstand extreme vibration, temperature fluctuations, and dust in heavy-duty transportation scenarios.
Core Function
-
Dual-Mode Data Display: Integrates analog gauges for real-time observation of core parameters (engine speed, vehicle speed) and a digital screen for precise display of fuel level, coolant temperature, oil pressure, odometer, trip meter, and fault codes, realizing comprehensive vehicle status monitoring.
-
Intelligent Fault Diagnosis: Reads and displays vehicle ECU fault codes in real time, with visual and audible alarm prompts for abnormal parameters (e.g., overheating, low oil pressure), helping drivers and maintenance personnel quickly locate and resolve faults.
-
Harsh Environment Adaptability: IP65-level sealed design prevents dust and moisture ingress; high-temperature resistant electronic components and shock-absorbing brackets ensure stable operation in high-temperature, low-temperature, and high-vibration working conditions.
-
Plug-and-Play Compatibility: Matches the original vehicle’s CAN bus waterproof connector and precise positioning mounting feet, supporting direct replacement without rewiring or programming, greatly reducing maintenance time and costs.
Digital Meter Dashboard DZ97189584116 SHACMAN – OEM Instrument Cluster for Heavy-Duty Trucks
When your fleet depends on accurate, real-time data in the harshest operating conditions, the Digital Meter Dashboard DZ97189584116 SHACMAN delivers exactly that. Engineered as a direct OEM replacement for Shacman heavy-duty truck models, this intelligent instrument assembly merges classic analog gauges with a modern high-resolution digital display — giving drivers and fleet managers the clarity they need at a glance. At Mettlead, we supply this dashboard assembly at factory-direct pricing with reliable global logistics, so your trucks stay on the road and your procurement stays on budget.
Key Features and Benefits of the Digital Meter Dashboard DZ97189584116 SHACMAN
This instrument cluster is far more than a simple gauge panel. Every element of the Digital Meter Dashboard DZ97189584116 has been purpose-built for the demanding world of heavy-duty transportation. Here is what sets it apart:
Hybrid Display Architecture
The assembly combines precision analog mechanical gauges — a tachometer reading 0–2500 rpm and a speedometer covering 0–140 km/h — with a centrally mounted high-resolution digital screen. This dual-format layout allows drivers to absorb critical information quickly, reducing eye fatigue during long hauls.
Rugged Construction for Extreme Environments
Heavy trucks face relentless vibration, temperature swings from freezing cold to scorching heat, and constant dust exposure. To handle all of this, the SHACMAN Digital Meter Dashboard DZ97189584116 features:
- A scratch-resistant polycarbonate (PC) cover that maintains optical clarity over years of use
- A robust ABS plastic housing that resists cracking and UV degradation
- A reinforced shock-absorbing mounting structure that isolates sensitive electronics from chassis vibration
Advanced EMI Shielding and Sealed Electronics
The fully sealed circuit board incorporates anti-electromagnetic interference (EMI) treatment. In practice, this means the dashboard readings remain stable and accurate even when operating near high-power electrical systems, CB radios, or aftermarket accessories — a common pain point with lower-quality replacement clusters.
Ergonomic, Driver-Centric Design
The integrated ergonomic layout positions every gauge and indicator within the driver's natural line of sight. Consequently, operators spend less time searching for information and more time focused on the road ahead.
Direct OEM Fitment
Because this is a genuine OEM-spec part carrying the original part number DZ97189584116, it drops directly into compatible SHACMAN truck models without wiring modifications or adapter brackets. That translates to faster installation, lower labor costs, and zero compatibility headaches for your maintenance team.
Technical Specifications – Digital Meter Dashboard DZ97189584116 SHACMAN
| Parameter | Specification |
|---|---|
| OEM Part Number | DZ97189584116 |
| Compatible Brand | SHACMAN (Shaanxi Auto) |
| Product Type | Intelligent Instrument Assembly / Digital Meter Dashboard |
| Tachometer Range | 0–2500 RPM |
| Speedometer Range | 0–140 km/h |
| Central Display | High-resolution digital LCD screen |
| Cover Material | Scratch-resistant Polycarbonate (PC) |
| Housing Material | ABS Engineering Plastic |
| Circuit Protection | Full-sealed PCB with anti-EMI treatment |
| Mounting | Reinforced shock-absorbing structure |
| Operating Environment | Extreme vibration, wide temperature range, high dust |
| Packaging Options | Original / Neutral / Custom (white-label available) |
| Origin | China |
OEM and ODM Capabilities – Tailored to Your Market
As a procurement manager, you likely serve diverse markets with different branding and packaging requirements. Mettlead understands this, which is why we offer flexible options for the Digital Meter Dashboard DZ97189584116 SHACMAN and our entire SHACMAN parts catalog.
White-Label and Custom Packaging
Whether you need neutral boxes for aftermarket distribution or fully branded packaging with your company logo, our team handles it. Minimum order quantities for custom packaging are negotiable — just let us know your volume expectations.
Strict Quality Control
Every Digital Meter Dashboard DZ97189584116 leaving our facility passes through a multi-point inspection process. We verify electrical continuity, gauge calibration accuracy, display pixel integrity, and housing seal tightness before packing. As a result, defect rates remain consistently low, protecting your reputation with end customers.
Broad Parts Coverage
Beyond this dashboard, Mettlead supplies a comprehensive range of electrical system components and SHACMAN truck engine parts — from ECU modules and wiring harnesses to sensors and lighting assemblies. Consolidating your orders with a single supplier simplifies logistics and often unlocks better pricing.
Factory-Direct Advantage
We work directly with manufacturing facilities in China, eliminating middlemen. For you, that means competitive unit costs, shorter lead times, and a direct communication channel to resolve technical questions without delays.
Frequently Asked Questions
Which SHACMAN truck models does the Digital Meter Dashboard DZ97189584116 fit?
This instrument assembly is designed as a direct replacement for SHACMAN heavy-duty truck models that originally use part number DZ97189584116. If you are unsure about compatibility with your specific model or year, send us your vehicle identification details and our technical team will confirm fitment within 24 hours.
What is the typical lead time for bulk orders?
For standard stock quantities, we typically ship within 3–7 business days. Larger bulk orders or custom-packaged shipments may require 10–15 business days depending on volume. We always confirm exact timelines before you commit to an order.
Can I request a sample of the SHACMAN Digital Meter Dashboard DZ97189584116 before placing a bulk order?
Absolutely. We encourage sampling, especially for first-time buyers. Sample units ship quickly so you can verify fitment, build quality, and display performance before scaling up your order.
What payment methods does Mettlead accept?
We support multiple secure payment channels including T/T (bank transfer), Western Union, and trade assurance options. Our team will work with you to find the most convenient and secure method for your region.
Do you offer warranty coverage on this dashboard assembly?
Yes. All genuine parts supplied by Mettlead carry a quality warranty. Specific terms depend on order volume and product category — reach out to our sales team for full warranty details on the Digital Meter Dashboard DZ97189584116.
Can I visit your facility before placing a large order?
We welcome factory visits and inspections. Many of our long-term partners started their relationship with an on-site visit. Contact us to arrange a convenient date, and we will handle the logistics on our end.
Ready to Secure Your Supply of the Digital Meter Dashboard DZ97189584116 SHACMAN?
Whether you need a single sample or a container-load shipment, our team is prepared to provide competitive pricing, accurate lead times, and technical support for the Digital Meter Dashboard DZ97189584116 SHACMAN. Getting started takes less than a minute.
Contact us now
with your required quantity and delivery destination — we will respond with a detailed quotation within 24 hours. No obligation, no pressure, just straightforward pricing from a supplier that understands heavy-duty truck parts inside and out.
