Upper Thrust Rod Assembly DZ91259525274 SHACMAN

Product Introduction

Structure

This upper thrust rod assembly features a one-piece forged alloy steel rod body with a high-strength black anti-corrosion finish. Both ends are integrated with precision-machined forged steel yoke connectors, each with dual-lug mounting interfaces designed for pivot pin installation. The rod body has a reinforced stepped structure at the joint with the yokes, and the surface is treated with anti-fatigue rolling to enhance structural integrity under dynamic loads.

Performance

Forged from premium 42CrMo alloy steel and heat-treated for optimal strength and toughness, it withstands extreme tensile, compressive, and lateral shear forces up to 120kN. The component maintains stable mechanical properties in temperatures ranging from -40°C to 120°C, and the anti-corrosion coating resists rust, gravel abrasion, and chemical corrosion. It ensures a service life of over 600,000 km in heavy-duty truck and engineering vehicle applications.

Core Function

1. Serves as a key component of the heavy-duty suspension system, limiting the longitudinal and lateral displacement of the drive axle relative to the frame to maintain optimal axle alignment.

2. Transmits traction and braking forces between the axle and frame, ensuring efficient power transfer and stable braking performance under full-load conditions.

3. Restricts excessive axle oscillation during acceleration, braking, and cornering, reducing tire wear and improving the vehicle’s overall driving stability.

4. Maintains the geometric position of the suspension system, preventing abnormal wear of transmission components and ensuring the reliable operation of the entire powertrain.
