Tow Hook Assembly DZ95189840010 SHACMAN

Product Introduction

Structure

This tow hook assembly is a heavy-duty forged steel component, featuring a robust U-shaped clevis with an integrated threaded shank. It includes a precision-machined pivot pin secured by a spring-loaded cotter pin for reliable locking, and the entire assembly is coated with a black anti-corrosion finish to resist rust and wear in heavy-duty environments. The clevis design allows for secure attachment to towing hardware, while the threaded shank provides a strong connection to the vehicle’s chassis or traction hook seat.

Performance

Forged from high-strength alloy steel and heat-treated for maximum toughness, it withstands extreme tensile loads up to 200kN, making it suitable for heavy-duty truck and engineering vehicle towing operations. The anti-corrosion coating provides reliable protection against harsh weather, salt spray, and chemical corrosion, ensuring consistent performance in temperatures ranging from -40°C to 120°C. The pivot pin and cotter pin design prevents accidental disengagement, enhancing safety during towing.

Core Function

1. Provides a secure and reliable connection point for towing hardware, enabling the vehicle to be towed or to tow other heavy equipment safely.

2. Transmits high tensile forces from the towing hardware to the vehicle’s chassis, distributing loads evenly to prevent structural damage during towing operations.

3. Ensures quick and secure engagement and disengagement of towing hardware, with the cotter pin preventing accidental release under load.

4. Serves as a critical safety component in the vehicle’s towing system, designed to meet heavy-duty load requirements and ensure safe operation under extreme conditions.
