Range Gear Syn. Sliding Sleeve WG2210100008 SINOTRUK HW SERIES GEARBOX
1
| Product Name | Range Gear Syn. Sliding Sleeve |
| Product Number | WG2210100008 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | Carton |
| Application | SINOTRUK HW SERIES GEARBOX |
| Original | China |
Shipping and Delivery
We offer spare parts for most Chinese truck brands and provide comprehensive, turnkey procurement services. For more information on specific vehicle models or parts, please contact us.Transactions are processed through the receiving bank (VTB).
Product Description
Product Introduction
This sliding sleeve is a critical component for engaging high/low gear ranges, translating the force from the shift fork into a synchronized gear engagement.
-
Structure & Material: Manufactured from high-strength 20CrMnTi alloy steel, with an internal splined bore and external gear teeth. The inner splines mesh with the range gear seat, while the outer teeth engage with the planetary gear set.
-
Heat Treatment: Full carburizing and quenching processes achieve a surface hardness of HRC 58–62 for wear resistance, while maintaining a core hardness of HRC 33–45 for impact toughness. The green coating on the splines enhances lubrication and reduces friction.
-
Precision Fit: Machined to tight tolerances, it ensures smooth axial movement and precise meshing with both the range gear seat and planetary gear set.
Core Function
-
Range Engagement: Moves axially under the action of the shift fork to engage either high or low range by meshing with the planetary gear set.
-
Synchronized Torque Transfer: Transmits torque from the range gear seat to the planetary gear set, ensuring power delivery during range shifts.
-
Clash-Free Shifting: Works with the synchronizer ring to equalize rotational speeds, enabling smooth, clash-free engagement between gear components.
