Power Cylinder Bracket AZ2229260015 SINOTRUK HW SERIES GEARBOX
1
| Product Name | Power Cylinder Bracket |
| Product Number | AZ2229260015 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | The packaging will be treated to prevent drops, rust, and impacts. |
| Application | SINOTRUK HW SERIES GEARBOX |
| Original | China |
Shipping and Delivery
We offer spare parts for most Chinese truck brands and provide comprehensive, turnkey procurement services. For more information on specific vehicle models or parts, please contact us.Transactions are processed through the receiving bank (VTB).
Product Description
Product Introduction
This bracket is a key structural component that secures the power cylinder, ensuring reliable operation of the transmission’s range shift mechanism.
-
Structure & Material: Precision-cast from high-strength ductile iron, with an integrated L-shaped design and multiple mounting holes for bolted installation. The bracket features a curved support surface that matches the profile of the power cylinder.
-
Strength & Stability: The robust casting and reinforced load-bearing areas provide rigid support for the power cylinder, withstanding the high forces generated during range shifts.
-
Precision Alignment: Machined mounting surfaces ensure the power cylinder is positioned accurately, maintaining proper alignment with the shift fork and range sleeve.
Core Function
-
Secure Mounting: Provides a rigid, vibration-resistant mounting point for the range shift power cylinder.
-
Force Transfer: Transmits the actuation force from the power cylinder to the shift fork, enabling reliable high/low gear ratio switching.
-
Alignment Maintenance: Ensures the power cylinder remains correctly aligned with the shift mechanism, preventing wear and improving shift accuracy.
