Output Shaft AZ2225100001 SINOTRUK HW SERIES GEARBOX
1
| Product Name | Output Shaft |
| Product Number | AZ2225100001 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | The packaging will be treated to prevent drops, rust, and impacts. |
| Application | SINOTRUK HW SERIES GEARBOX |
| Original | China |
Shipping and Delivery
We offer spare parts for most Chinese truck brands and provide comprehensive, turnkey procurement services. For more information on specific vehicle models or parts, please contact us.Transactions are processed through the receiving bank (VTB).
Product Description
Product Introduction
-
Structure: A precision monoblock forging from 40CrNiMo alloy steel, integrating a full-length splined shaft and a mounting flange. The splined section features 54 external involute splines (φ110mm) for engagement with the differential, while the flange has 4 bolt holes for drive shaft connection. The entire component undergoes carburizing, quenching, and precision grinding, achieving surface hardness HRC 55–60(anti-wear) and core hardness HRC 35–40 (high impact toughness). The rear end has a threaded bore for locking the shaft nut.
-
Performance: The monoblock forging eliminates assembly gaps, ensuring exceptional torsional rigidity for ultra-heavy load transmission. The carburized spline surface resists wear from differential rotation, maintaining a secure connection for over 80,000 hours of operation.
Core Function
-
Ultra-heavy load power output: Transmits torque from the transmission differential to the drive shaft, supporting the highest load capacity of the HW25712 transmission.
-
Differential engagement: The splined shaft engages with the differential side gear, transferring power from the transmission to the driveline.
-
Drive shaft connection: The integral flange provides a rigid mounting point for the drive shaft, ensuring concentric alignment and reducing vibration.
