Oil Pump Body AZ2222240001 SINOTRUK HW SERIES GEARBOX
1
| Product Name | Oil Pump Body |
| Product Number | AZ2222240001 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | The packaging will be treated to prevent drops, rust, and impacts. |
| Application | SINOTRUK HW SERIES GEARBOX |
| Original | China |
Shipping and Delivery
We offer spare parts for most Chinese truck brands and provide comprehensive, turnkey procurement services. For more information on specific vehicle models or parts, please contact us.Transactions are processed through the receiving bank (VTB).
Product Description
Product Introduction
-
Structure: Precision cast from high-strength HT250 gray cast iron, with an integrated mounting flange featuring 4 bolt holes for securing to the transmission housing. The inner cavity is precision-machined to match the oil pump rotor and internal gear ring, with an inlet port and outlet port for oil flow. The surface undergoes anti-rust painting to resist corrosion from transmission oil and moisture, and the flange face is sealed with a rubber gasket to prevent oil leakage.
-
Performance: The rigid cast iron body maintains precise cavity dimensions under high-pressure operation, preventing rotor misalignment that would reduce pump efficiency. The precision-machined cavity ensures uniform clearance between the rotor and gear ring, maintaining stable oil pressure (0.2–0.6 MPa) across all operating conditions. The anti-rust coating and gasket seal ensure a leak-free service life exceeding 50,000 hours.
Core Function
-
Pump cavity housing: Provides a rigid, precision-machined cavity for the oil pump rotor and internal gear ring, enabling the gerotor pump to generate oil pressure.
-
Oil flow routing: Directs oil from the transmission sump (via the inlet port) to the lubrication circuit (via the outlet port).
-
Sealed mounting: The flange and gasket seal the pump to the transmission housing, preventing oil leakage into the main gearbox cavity.
