Main Shaft 3rd Gear AZ2210040225 SINOTRUK HW SERIES GEARBOX
1
| Product Name | Main Shaft 3rd Gear |
| Product Number | AZ2210040225 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | The packaging will be treated to prevent drops, rust, and impacts. |
| Application | SINOTRUK HW SERIES GEARBOX |
| Original | China |
Shipping and Delivery
We offer spare parts for most Chinese truck brands and provide comprehensive, turnkey procurement services. For more information on specific vehicle models or parts, please contact us.Transactions are processed through the receiving bank (VTB).
Product Description
Product Introduction
-
Structure: Precision forged from 20CrMnTi alloy steel, featuring an external involute tooth profile (38 teeth) and internal splines (18 teeth) for engagement with the main shaft. The gear is integrated with a synchronizer friction cone, and the intermediate ring has 6 lightening holes to reduce rotational inertia. The entire gear undergoes full carburizing, quenching, and precision grinding, achieving surface hardness HRC 58–62(anti-pitting/wear) and core hardness HRC 33–45 (anti-impact fracture). The friction cone surface is coated with molybdenum disulfide (MoS₂) for enhanced synchronization performance.
-
Performance: The MoS₂-coated friction cone enables rapid speed synchronization (≤0.4s per shift) during 3rd gear engagement, even under 2500N·m torque. The carburized tooth surface resists pitting and wear in long-term cruising scenarios, while the lightening holes reduce rotational inertia to improve shift responsiveness. The precision-ground tooth profile ensures smooth meshing with the countershaft 3rd gear, minimizing noise and vibration.
Core Function
-
3rd gear power transmission: Transmits torque from the main shaft to the countershaft 3rd gear, providing a medium torque ratio for steady-speed heavy-load cruising (60–80 km/h).
-
Synchronization cooperation: The integrated friction cone works with the 3rd gear synchronizer ring to equalize speeds, enabling smooth shifting under load.
-
Reduced rotational inertia: The lightening holes lower gear inertia, improving shift speed and reducing synchronizer wear.
