Input Shaft End Cover And Oil Guide Ring Assy AZ2203020106 SINOTRUK HW SERIES GEARBOX
1
| Product Name | Input Shaft End Cover And Oil Guide Ring Assy |
| Product Number | AZ2203020106 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | The packaging will be treated to prevent drops, rust, and impacts. |
| Application | SINOTRUK HW SERIES GEARBOX |
| Original | China |
Shipping and Delivery
We offer spare parts for most Chinese truck brands and provide comprehensive, turnkey procurement services. For more information on specific vehicle models or parts, please contact us.Transactions are processed through the receiving bank (VTB).
Product Description
Product Introduction
-
Structure: An integrated assembly consisting of a cast iron end cover and a precision-machined aluminum alloy oil guide ring. The end cover features a hexagonal mounting flange with 6 bolt holes for secure attachment, and a central bore that supports the input shaft front bearing. The oil guide ring is press-fitted into the cover’s inner bore, with spiral oil grooves to direct lubricant to the input shaft journal and bearing.
-
Key Specifications:
-
Material: Ductile cast iron (end cover) + aluminum alloy (oil guide ring)
-
Mounting: 6-point M10 bolted connection
-
Surface treatment: Anti-rust black oxide (cast iron) + anodized (aluminum ring)
-
Operating temperature: -40°C to +150°C
Core Function
-
Sealing Protection: Seals the front opening of the transmission main box, preventing lubricating oil leakage and blocking dust/moisture from entering the transmission.
-
Lubrication Guidance: The oil guide ring’s spiral grooves direct pressurized oil from the lubrication circuit to the input shaft journal and front bearing, ensuring continuous lubrication and cooling.
-
Bearing Support: The central bore of the end cover provides precise radial support for the input shaft front bearing, maintaining shaft concentricity and reducing vibration.
