Idler Gear WG2210050001 SINOTRUK HW SERIES GEARBOX
1
| Product Name | Idler Gear |
| Product Number | WG2210050001 |
| MOQ | 1 |
| Warranty period | 3 Months |
| Package | The packaging will be treated to prevent drops, rust, and impacts. |
| Application | SINOTRUK HW SERIES GEARBOX |
| Original | China |
Shipping and Delivery
We offer spare parts for most Chinese truck brands and provide comprehensive, turnkey procurement services. For more information on specific vehicle models or parts, please contact us.Transactions are processed through the receiving bank (VTB).
Product Description
Product Introduction
-
Structure: Precision-forged from high-strength 20CrMnTi alloy steel, with an external involute gear tooth profile and a smooth inner bore. The gear is carburized, quenched, and ground to achieve a surface hardness of HRC 58–62and a core hardness of HRC 33–45, balancing wear resistance and toughness.
-
Key Specifications:
-
Number of teeth: 21 teeth
-
Material: 20CrMnTi carburized steel
-
Surface treatment: Carburizing + quenching + gear grinding
-
Operating temperature: -40°C to +150°C
-
Performance: The hardened tooth surface resists pitting and wear under high torque loads, while the tough core withstands shock loads during reverse engagement. Precision-ground teeth ensure smooth meshing and minimal noise.
-
Core Function
-
Power Redirection: Transmits torque between the main shaft reverse gear and countershaft reverse gear, changing the direction of rotation to enable vehicle reverse travel.
-
Torque Transmission: Handles high reverse gear torque loads without deformation or failure.
-
Noise Reduction: Precision-ground tooth profile ensures smooth, quiet meshing with mating gears.
