Gearbox Main Shaft F99882 Fast Gear

Product Introduction

• Structure: An integral precision-forged shaft made from high-strength nickel-chromium alloy steel, with multi-section external splines and a threaded end for secure nut fastening. The surface undergoes carburizing, quenching, and precision grinding for maximum hardness (HRC58-62) and a smooth finish. The shaft features a stepped design with varying spline counts to accommodate different gear ratios and torque loads, and a black oxide coating for corrosion resistance.

• Performance: The high-hardness spline surfaces withstand extreme torque and shear forces, while the integral forging ensures exceptional torsion and bending resistance, preventing deformation or fracture under heavy load. The precision-ground splines ensure smooth meshing with synchronizer hubs and gears, minimizing friction and wear. The threaded end provides a secure, lockable connection to the drive axle, ensuring reliable power transfer.

Core Function

1. Final Torque Output: Transmits rotational torque from the transmission gear train to the drive axle, delivering power to the vehicle’s wheels.

2. Spline Power Transfer: The multi-section splines form rigid connections with synchronizer hubs and gears, ensuring efficient torque transmission across different gear ratios.

3. Heavy-Duty Load Handling: The high-strength alloy steel and integral forging safely handle the extreme torque of heavy hauling, climbing, and frequent gear shifting.
