Front Leaf Spring Assembly DZ95319690914 SHACMAN

Product Introduction

Structure

This front leaf spring assembly adopts a multi-layer progressive laminated structure, composed of high-strength spring steel plates with different lengths and curvatures. It is equipped with heavy-duty spring clamps, a reinforced main leaf with an integrated eyelet, a precision-machined shackle end, and high-wear rubber bushings at both mounting ends. The whole assembly is coated with a black electrophoretic anti-corrosion layer to ensure structural stability and environmental adaptability.

Performance

Designed for heavy-duty working conditions, the assembly has excellent load-bearing capacity and fatigue resistance, and can withstand repeated bending and extreme impact loads. It maintains stable elastic performance in the temperature range of -40°C to 120°C, and the anti-corrosion coating effectively resists rust, salt spray and gravel wear, ensuring a long service life under standard heavy-duty truck operation.

Core Function

1. As the core load-bearing component of the front suspension system, it bears the vertical load of the front of the vehicle and ensures stable ground clearance of the front axle under full load.

2. Absorbs and buffers impact and vibration from the road surface, isolating harsh jolts from the chassis and cab, and improves driving comfort for heavy-duty trucks.

3. Transmits longitudinal traction and braking forces, as well as lateral steering forces from the front axle to the frame, ensuring accurate steering response and stable braking performance.

4. Maintains geometric alignment of the front suspension, prevents front axle displacement, and ensures safe and reliable operation during high-speed driving, cornering and emergency braking.
