Cross Beam WG9725593010 Sinotruk

Product Introduction

Structure

This cross beam is a welded integral structural component custom-engineered for heavy-duty truck chassis systems. It features a core structure of a high-strength steel pipe bent into an optimized arc profile, welded at both ends to thickened rectangular steel mounting flanges with precision-drilled bolt holes. Reinforcing rib plates are welded between the pipe body and flanges to enhance structural stability. The entire assembly is finished with a matte gray anti-corrosion coating, and all welding seams are smooth and uniform to ensure structural integrity and load-bearing capacity.

Performance

Fabricated from high-quality structural alloy steel and processed through professional welding and heat treatment, the cross beam exhibits outstanding tensile strength, bending resistance, and fatigue durability.  The anti-corrosion coating provides superior protection against rust, salt spray, and gravel abrasion, while the precision-machined mounting holes ensure accurate alignment with the chassis frame, avoiding installation deviations and stress concentration.

Core Function

1. Serves as a key load-bearing and connecting component of the truck chassis, connecting the left and right frame rails to enhance the overall rigidity and torsional strength of the chassis.

2. Bears and distributes vertical, horizontal, and torsional loads from the cargo body, suspension system, and road surface, preventing deformation or fracture of the chassis frame.

3. Provides a stable mounting base for auxiliary components such as fuel tanks, air compressors, or suspension brackets, ensuring the reliable fixation of these parts during vehicle operation.
