Cabin Front Suspension Shock Absorber Bottom Bracket 810W41701-0076 Sinotruk Sitrak

Product Introduction

Structure

This cabin front suspension shock absorber bottom bracket adopts an integrated precision stamping and forming process with high-strength structural steel as the base material, featuring a streamlined triangular reinforced design to maximize structural rigidity while achieving lightweight optimization. The bracket is equipped with a central cylindrical pivot sleeve (precision-machined for shock absorber installation) and multiple counterbored mounting holes on the irregular contour edge for chassis fixation.

Performance

Made of high-grade high-strength structural steel, the bracket undergoes overall strengthening heat treatment, exhibiting excellent impact resistance and fatigue resistance, and can stably withstand the continuous alternating damping reaction forces generated by the shock absorber under heavy-duty vehicle operation. The gray electrophoretic coating has strong adhesion and provides superior protection against gravel impact, salt spray corrosion and industrial chemical erosion, maintaining stable mechanical properties in the temperature range of -40°C to 150°C.

Core Function

1. Serves as the core lower mounting carrier for the cabin front suspension shock absorber, providing a fixed pivot point to ensure the normal telescopic damping movement of the shock absorber.

2. Transmits the downward damping reaction force from the shock absorber to the vehicle chassis, and disperses the concentrated load to the larger stress-bearing area of the chassis through the triangular structure, avoiding local structural damage.

Ensures the precise vertical installation angle of the shock absorber, maintains the optimal matching state between the shock absorber and the cabin
