Balance Shaft Bracket

Product Introduction

Structure

This balance shaft bracket is a precision-cast ductile iron component, featuring a robust U-shaped design optimized for heavy-duty truck chassis integration. The main body is a rib-reinforced casting, with a central cylindrical bore for balance shaft mounting and two side mounting lugs with precision-machined holes for chassis attachment. The entire assembly is finished with a matte gray anti-corrosion coating, and a label with the part number “WG9100520034” is affixed for easy identification.

Performance

Constructed from high-grade ductile iron, the bracket offers exceptional structural rigidity, impact resistance, and fatigue strength, capable of withstanding the extreme loads and stresses encountered in heavy-duty operation. The precision-machined mounting holes ensure accurate alignment and secure attachment of the balance shaft and associated components, while the rib-reinforced design optimizes load distribution, preventing localized stress concentrations and component failure. The anti-corrosion coating provides superior resistance to rust, salt spray, and chemical corrosion, ensuring long-term durability in diverse operating conditions, with a temperature range of -40°C to 120°C.

Core Function

1. Serves as a critical mounting interface for the balance shaft, providing a secure and stable attachment point to the chassis, ensuring proper alignment and load distribution.

2. Transmits and distributes complex loads such as vertical pressure, lateral torque, and longitudinal impact from the balance shaft to the chassis, maintaining the integrity of the suspension system.

Maintains precise alignment of the balance shaft and associated components, preventing relative displacement under dynamic conditions such as vehicle acceleration, braking, and turning, avoiding abnormal wear of suspension parts
